Host size |
47 * 23 * 11MM |
Host Material |
PC |
Band length |
215mm |
BraceletStuff |
TPU |
Clasp |
The nickel copper |
Weight |
25G |
Strap Installation |
Replaceable |
Strap Color |
Black |
Water level |
IP65 |
Core parameters |
Master |
Cortex-M4 core |
Bluetooth |
BLE4.0 |
RAM |
4M |
Accelerometer |
Triaxial accelerometer |
Heart rate sensor |
PPG (photoplethysmography plethysmography) |
Display |
Blue OLED 64 * 64 |
Vibration motor |
Cylindrical motor |
Key way |
Touch buttons |
Electrical performance parameters |
Battery |
Polymer |
Capacity |
110mha |
Charging |
Clip-charge |
Power requirements |
5V 1000ma |
Charging duration |
1C charge 1-2 hours |
Standby time |
Maximum 5 days |
Continuous Heart Rate |
12-18 hours |
Bracelet features |
Clock and date |
Demand and mobile phone synchronization |
Pedometer |
Stand by |
Calories |
Stand by |
Course |
Stand by |
Resting heart rate |
Stand by |
Dynamic Heart Rate |
15 km of the largest rhythmic movement |
Heart Rate Training |
Heart outline, |
Fatigue monitoring |
can manually measure fatigue |
Motion Detection |
Offline monitoring movement (including heart rate) |
PSG |
Off-line monitoring of sleep (including heart rate) |
Silent alarm (can be customized) |
Phone-side setting, bracelet end reminder (icon form, can be customized) |
Anti-lost reminder |
Disconnect bracelet vibrate |
Calls to remind |
Caller ID, caller name |
SMS alerts (text message content) |
Can display content |
Micro-channel interfaces |
debugging, does not support |
Data storage |
30 days of daily data |
20 Sports and sleep time is stored (including heart rate) |
Each time up to 12 hours |
Software features |
Data synchronization |
Connected, 5 minutes automatically synchronized once |
Historical data |
Store 7 days |
Trend Analysis |
Day, week, month, year, (all day and sleep) |
Day data details |
Number of steps, calories, intensity |
Chart Analysis |
Steps curve |
Degree of completion |
Percentage |
Motion data details |
Duration, number of steps, calories, optional heart rate (average, maximum) |
Chart Analysis |
Step curve, heart rate curve, heart rate zones |
Motion data comparison |
The same type of motion Contrast |
Sleep data details |
Sleep long, deep sleep, light sleep, waking statistics |
Curve analysis |
Sleep curve, heart rate curve |
Real-time heart rate monitor |
Real-time measurements in the mobile phone side, with the type of movement |
Fatigue monitoring |
Irregular automatic measurements |
Family friendly |
Share fatigue data and the weekly trend to relatives |
Movement Goal Setting |
Target number of steps |
Equipment Management |
Add or cancel equipment |
Remote Upgrade |
Firmware and sensor algorithm optimization and upgrading |
Software Compatibility |
IOS |
It has been on-line |
Andrews |
Test |
Language Version |
In the British version of IOS, android Chinese version, |
Standard BLE4.0 agreement |
It supports a variety of famous sports software |
Support third-party software developers |
It may open API interfaces |
Giftbox(W*D*H) |
108mm*85mm*75mm27g |
